Aerpro G45CL Stealth Registration Plate Reverse Camera With Loop System

Description:

The Gator G45CL Stealth Registration Plate Reverse Camera is a compact reverse camera that has been designed to mount behind any standard size Australian registration plate. Ideally it suits vehicles with a centrally mounted registration plate in order to gain the best viewing angle. The biggest advantage of this design is that no additional holes need to be drilled for mounting the camera and all of the mounting hardware is virtually invisible as it is hidden behind the registration plate. It features built in parking grid lines that will help guide you when reverse parking, a 120 degree viewing angle that will eliminate blind spots, a sturdy aluminum case and is even IP67 rated. The camera also features a 4 pin micro din connector that allows for a clean and simple installation.

A very special feature available on this camera is the Loop System. The camera has three wire loops on the wiring and at time of installation you can make the following adjustments by simply cutting the specific loop:

• BLUE - default setting NTSC, cut the loop for PAL.
• GREEN - default setting NO parking grid lines, cut the loop for parking grid lines.
• WHITE - default setting rear view image, cut the loop for reverse image.

The camera is PAL/NTSC switchable and is supplied with a standard RCA cable so it can be connected to any monitor or in dash AV head unit that has an RCA camera input. If you are unsure simply refer to the monitors specifications.

The camera comes supplied with power wire and a 5.5m video RCA. This camera is a great option for anyone looking for a compact, registration plate mount, high quality camera.

Features:

• Stealth Registration Plate Mount Reverse Camera
• 120 Degree Super Wide Angle
• Loop System For Adjustable Settings
• IP 67 Rated
  ** not canbus suitable **

Specs:

• Resolution: 480TV Lines
• Mount Type: Registration Plate
• Reverse or Rear View: Switchable Reverse/Rear View
• Lens Angle: 120 Degrees
• CMOS or CCD: CMOS
• Parking Gridlines: Switchable On/Off
• PAL or NTSC: Switchable PAL/NTSC
• IP Rating: IP67
• Voltage: 12V
• Minimum Illumination: 0.2lux
• Number of LED'S: N/A
• LED Type: N/A
• Plug Type Camera End: 4 Pin Micro Din Plug
• Plug Type Monitor End: RCA
• Length of Video Cable: 6m
• Reverse Trigger on Video Cable: Yes
• Dimensions (Camera Only):
  15mm(H) x 15mm(W) x 21 mm(L)
• Dimensions (Camera & Bracket):
  40mm(H) x 365mm(W) x 35 mm(L)

• Other Features: Loop System

• Blue - default setting NTSC, cut the loop for pal.

• Green - default setting NO parking gridlines, cut the loop for parking gridlines.
• White - default setting rear view image, cut the loop for reverse image
